Application
System | |
---|---|
Processor |
Intel® 11th generation Core i7 1165G7 / i5 1135G7 |
System Memory |
DDR4 up to 64GB |
Storage Disk Drive |
m.2 SSD up to 1TB |
OS Support |
Microsoft® Windows 10 Microsoft® Windows® 11 Ubuntu IGEL |
Security |
Barcode reader (optional) Imprivata RFID reader (optional) Smart Card Reader (optional) Trusted Platform Module 2.0(TPM 2.0) |
Speaker |
3W x2 |
Wireless Communication |
802.11 ac/a/b/g/n + BT 4.1 (optional) Wifi6 + BT 5.2 (optional) |
Power |
19V DC-in x1 |
Display | |
---|---|
Size |
24" |
Resolution |
1920 x 1080 |
Luminance |
250nits |
Touch Screen |
PCT (optional) |
Contrast Ratio |
3000:1 |
Max. Colors |
16.7M |
I/O | |
---|---|
USB |
USB 2.0 x2 USB 3.0 x 4 |
Ethernet |
1.5kv isolated Gigabit LAN x2 |
Audio |
Combo audio port x1 |
COM |
Combo port x2 |
Video Out |
HDMI 1.4 x1 |
Mechanical and Environmental | |
---|---|
Operating Temperature |
0°C ~ 35°C(32°F ~ 95°F) |
Storage Temperature |
-20°C ~ 60°C(-4°F ~ 140°F) |
Dimension |
560(L) x 78.4(W) x373(H) |
Package Size |
730(L) x 240(W) x 550(H)mm |
Gross Weight |
11 kg (24.25 lb) |
Net Weight |
7kg |
Mounting VESA |
75/100 mm VESA mount |
Certifications |
CE: EN 60601-1-2:2015(V4.0) CE:EN 60601-1:2006/A1:2013(V3.1) cUL: CAN/CSA-C22.2 No. 60601-1:2014 (V3.1) FCC: Part 18 Class B UL: ANSI/AAMI ES60601-1:2012 (V3.1) |
