System | |
---|---|
Processor |
Intel® 9th Generation Xeon E-2276ML 2.0GHz Six Core / Core i7-9850HL 1.9GHz Six Core |
System Memory |
ECC (for Xeon) / Non-ECC (for Core i7) DDR4 SODIMM up to 64GB |
Storage Disk Drive |
2.5” SATA Hard Disk Drive/Solid State Disk Drive x2 |
OS Support |
Microsoft® Windows 10 Linux® |
Security |
Trusted Platform Module 2.0(TPM 2.0) |
Speaker |
5W x 2 |
Wireless Communication |
802.11ac, Bluetooth 5.1 (optional) |
Expansion |
PCI Express[x16] x1, PCI Express[x4] x1, PCI Express[x1] x1) |
Chipset |
CM246 (for Xeon) |
Graphics |
N/A |
Function Key |
LCD Brightness Up/Down Power On/Off Touch Screen On/Off |
Camera |
N/A |
Power |
100~240V AC / Full loading : 75 Watts |
Display | |
---|---|
Size |
24" |
Resolution |
1920 x 1080 |
Luminance |
400 nits |
Touch Screen |
Capacitive Multi-Touch |
Contrast Ratio |
1000':1 |
View Angle |
178˚(H)/178˚(V) |
Max. Colors |
N/A |
Back Light Life Time |
30,000 Hours |
I/O | |
---|---|
USB |
USB 3.0 x 4 |
Ethernet |
Isolated Gigabit LAN x2 |
Audio |
Line out(optional) Mic(optional) |
Serial Port |
Isolated RS-232 x2(optional) |
COM |
N/A |
Video Out |
Display Port 1.4 x1 |
Video In |
N/A |
Mechanical and Environmental | |
---|---|
Operating Temperature |
0°C ~ 35°C(32°F ~ 95°F) |
Storage Temperature |
-20°C ~ 60°C(-4°F ~ 140°F) |
Dimension |
595 x 387 x 95 mm |
Package Size |
764 x 240 x 534 mm |
Gross Weight |
13 kg (28.7 lb) |
Net Weight |
11 Kg (24.3 lb) |
Mounting VESA |
VESA 100mm |
Degree of Protection |
IP54 in the front, IPX1 in the back |
Certifications |
CE: EN 60601-1-2:2015(V4.0) cUL: CAN/CSA-C22.2 No. 60601-1:2014 (V3.1) EN 60601-1:2006/ A1:2013(V3.1) FCC: Part 18 Class B UL: ANSI/AAMI ES60601-1:2012 (V3.1) |
