ACCEL-A2701
27”4K UHD 6th Generation Xeon / Core i7 Medial All in One PC for AI Inference
$3000 US and up
Price for reference only. Excludes import duties, tariffs, and any taxes. Final price based on official quotation.
Feature
- 27" 3840 x 2160
- Intel 6th Gen Xeon/Core i7
- PCI Express[x16] Slot for AI Accelerator
Details
Application
- Digital Operation Room
- Medical AI
- Radiology Unit
Specification
| System | |
|---|---|
| Processor |
Intel® 6th Generation Xeon E3-1505M v5 2.8GHz Quad Core / Core i7-6820QE 2.8GHz Quad Core |
| System Memory |
ECC (for Xeon) / Non-ECC (for Core i7) DDR4 SODIMM up to 32GB |
| Storage Disk Drive |
2.5” SATA Hard Disk Drive/Solid State Disk Drive x2 |
| OS Support |
Microsoft® Windows 7 Microsoft® Windows 10 Linux® |
| Security |
Trusted Platform Module 2.0(TPM 2.0) |
| Speaker |
5W x 2 |
| Wireless Communication |
802.11ac, Bluetooth 5.1 (optional) |
| Expansion |
PCI Express[x16] x1, PCI Express[x4] x1, PCI Express[x1] x1) |
| Chipset |
CM246 (for Xeon) |
| Graphics |
N/A |
| Function Key |
LCD Brightness Up/Down Power On/Off Touch Screen On/Off Video Input Select |
| Camera |
N/A |
| Power |
100~240V AC / Full loading : 90 Watts |
| Display | |
|---|---|
| Size |
27" |
| Resolution |
3840 x 2160 |
| Luminance |
250nits |
| Contrast Ratio |
1000':1 |
| View Angle |
178˚(H)/178˚(V) |
| Max. Colors |
N/A |
| Back Light Life Time |
30,000 Hours |
| I/O | |
|---|---|
| USB |
USB 3.0 x 4 |
| Ethernet |
Isolated Gigabit LAN x2 |
| Audio |
Line out(optional) Mic(optional) |
| Serial Port |
Isolated RS-232 x2(optional) |
| COM |
N/A |
| Video Out |
Display Port 1.4 x1 |
| Video In |
HDMI x1 |
| Mechanical and Environmental | |
|---|---|
| Operating Temperature |
0°C ~ 35°C(32°F ~ 95°F) |
| Storage Temperature |
-20°C ~ 60°C(-4°F ~ 140°F) |
| Dimension |
676 x 429 x 102 mm |
| Package Size |
820 x 575 x 230 mm |
| Gross Weight |
16 kg (35.3 lb) |
| Net Weight |
13.5 kg (29.76 lb) |
| Mounting VESA |
VESA 100mm |
| Degree of Protection |
IP54 in the front, IPX1 in the back |
| Certifications |
CE: EN 60601-1-2:2015(V4.0) cUL: CAN/CSA-C22.2 No. 60601-1:2014 (V3.1) FCC: Part 18 Class B UL: ANSI/AAMI ES60601-1:2012 (V3.1) |
