ACCEL-A3201
32” 4K UHD 6th Generation Xeon / Core i7 Medial All in One PC for AI Inference
$3000 US and up
This price is for reference only, the final price will depend on the specifications you choose.
Feature
- 32" 3840 x 2160
- Intel 6th Gen Xeon/ Core i7
- PCI Express[x16] Slot for AI Accelerator
Details
Application
- Digital Operation Room
- Medical AI
- Radiology Unit
Specification
| System | |
|---|---|
| Processor |
Intel® 6th Generation Xeon E3-1505M v5 2.8GHz Quad Core / Core i7-6820QE 2.8GHz Quad Core |
| System Memory |
ECC (for Xeon) / Non-ECC (for Core i7) DDR4 SODIMM up to 32GB |
| Storage Disk Drive |
2.5” SATA Hard Disk Drive/Solid State Disk Drive x2 |
| OS Support |
Microsoft® Windows 7 Microsoft® Windows 10 Linux® |
| Security |
Trusted Platform Module 2.0(TPM 2.0) |
| Speaker |
5W x 2 |
| Wireless Communication |
802.11 a/b/g/n/ac +BT 5.0 802.11 ac/a/b/g/n + BT 4.1 (optional) |
| Expansion |
PCI Express[x16] x1, PCI Express[x4] x1, PCI Express[x1] x1) |
| Chipset |
CM236 (for Xeon) QM170(for Core i7) |
| Graphics |
N/A |
| Function Key |
LCD Brightness Up/Down Power On/Off Touch Screen On/Off Video Input Select |
| Camera |
N/A |
| Power |
AC in 100~240V |
| Display | |
|---|---|
| Size |
32" |
| Resolution |
3840 x 2160 |
| Luminance |
350 nits |
| Touch Screen |
Capacitive Multi-Touch |
| Contrast Ratio |
1000':1 |
| View Angle |
178˚(H)/178˚(V) |
| Max. Colors |
N/A |
| Back Light Life Time |
30,000 Hours |
| I/O | |
|---|---|
| USB |
USB 3.0 x 4 |
| Ethernet |
Isolated Gigabit LAN x2 |
| Audio |
Line out(optional) Mic(optional) |
| Serial Port |
Isolated RS-232 x2(optional) |
| COM |
N/A |
| Video Out |
Display Port 1.4 x1 |
| Video In |
HDMI x1 |
| Mechanical and Environmental | |
|---|---|
| Operating Temperature |
0°C ~ 35°C(32°F ~ 95°F) |
| Storage Temperature |
-20°C ~ 60°C(-4°F ~ 140°F) |
| Dimension |
778 x 478 x 102mm |
| Package Size |
910 x 618 x 220 mm |
| Gross Weight |
21.5 kg (47.4 lb) |
| Net Weight |
18.5 kg (40.8 lb) |
| Mounting VESA |
VESA 100mm |
| Degree of Protection |
IP65 in the front ; IP54 in the back |
| Certifications |
CE: EN 60601-1-2:2015(V4.0) cUL: CAN/CSA-C22.2 No. 60601-1:2014 (V3.1) EN 60601-1:2006/ A1:2013(V3.1) FCC: Part 18 Class B UL: ANSI/AAMI ES60601-1:2012 (V3.1) |
